5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine

1 Set
MOQ
To Be Negotiable
Price
5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Gantry AC 5-Axis Waterjet
Cutting Size: 3000×2000mm /4000×2000mm (customizable)
Cutting Head Travel: 100–150mm
Cutting Accuracy: ±0.10mm/m
Max Output Pressure: 400MPa
Continuous Working Pressure: ≤380MPa
Max Water Flow: 5 L/min
Main Motor: 22kw
Power Supply: 380V/AC,50Hz
Highlight:

5 axis waterjet cutting machine

,

gantry water jet cutter

,

stone waterjet cutting machine
Basic Infomation
Place of Origin: Jinjiang, Fujian, China
Brand Name: Xianda Machinery
Certification: CE, IAF-recognized ISO9001
Model Number: 3020 Waterjet
Payment & Shipping Terms
Packaging Details: Wire rope lashing,Suitable for sea/air/land/rail transportation.
Delivery Time: 1 Month
Payment Terms: L/C,D/A,D/P,T/T
Supply Ability: 1000 Sets/Year
Product Description

Why Choose XIANDA & Our Brand Strength


XIANDA is a professional manufacturer specializing in CNC stone processing machinery. Our factory holds IAF-recognized ISO9001:2015 Quality Management System Certification and CE safety certification. Adhering to standardized production and strict quality control, we deliver stable, high-precision and export-compliant machines for global markets. We integrate independent R&D, precision manufacturing and complete after-sales services, providing reliable solutions for stone cutting, chamfering and custom profiling. Supported by flexible trade terms, full export documentation and lifelong online technical support, we supply cost-effective and durable stone machinery for worldwide customers.

5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine5 Axis Waterjet Cutting Machine, Gantry Water Jet Cutter, AC 5-axis Waterjet, Stone Waterjet Cutting Machine




Product Overview

This Gantry AC 5-Axis Waterjet Cutting Machine is widely used for stone mosaic, marble, granite, ceramic pattern inlay and metal fabrication. Equipped with AC 5-axis rotating cutting head, it realizes ±75° bevel and curved cutting in one pass to cut down manual polishing work and boost productivity.
Adopted two-stage cooling structure, no external cooling tower or chiller is needed, saving workshop space and power cost. The oil-immersed waterproof & sand-proof beam is well adapted to dusty stone processing environment and extends the service life of transmission parts. Fitted with Weihong bus CNC system, it supports direct CAD import for easy and stable operation. The non-powered abrasive hopper works with only compressed air, simple to maintain.


Application Range

  • Stone processing factory (marble, granite, mosaic), ceramic deep processing, metal parts cutting, decorative material customization

Technical Parameters

Item Specification
Type Gantry AC 5-Axis Waterjet
Cutting Size 3000×2000mm /4000×2000mm (customizable)
Cutting Head Travel 100–150mm
Cutting Accuracy ±0.10mm/m
Max Output Pressure 400MPa
Continuous Working Pressure ≤380MPa
Max Water Flow 5 L/min
Main Motor 22kW
Power Supply 380V/AC,50Hz
Abrasive Hopper Non-electric, ≥0.2MPa air supply

Minimum Order Quantity (MOQ)

  • MOQ: 1 Unit

Shipping Terms

  • Shipping Options: FOB, CIF, DAP and DDP trade terms are available. We offer sea freight for cost-effective bulk shipments, air freight for faster delivery, and land transport for regional orders.
  • Packaging: Machines are packed in heavy-duty custom wooden crates with shock-absorbing materials to ensure damage-free transit.
  • Documentation: We handle all export documentation, including customs declarations, technical certificates and compliance documents, to ensure seamless international shipment.

Service Cycle & FAQ

Warranty & Support

  • Warranty Period: 12 months warranty for machine components and CNC control system (excluding consumable parts).
  • Technical Support: Technical Support: Lifetime online support for operation guidance, troubleshooting and maintenance. On-site service is available within 72 hours, subject to regional availability.

Frequently Asked Questions


What materials can this 5-axis waterjet cut?
It can process marble, granite stone mosaic, ceramic inlay, as well as stainless steel, aluminum and other metals for bevel and curved shapes.
Does the machine need an external cooling tower?
No. It adopts two-stage cooling system, no cooling tower or chiller required.
What drawing formats are supported?
The CNC system supports CAD files including dxf, nc, cnc, plt, G-code and more
Is the machine operation friendly for new users?
Equipped with a dedicated human-machine interface with English system language and simple operating logic. It supports both manual parameter input and automatic path generation after file import. We provide detailed English operation manuals and lifelong online guidance, so new operators can master basic operation quickly.
Can you provide customized service?
Yes. We support personalized customization services, including local adaptive voltage adjustment, worktable specification optimization and functional customization according to customers processing scenarios. Customized exclusive processing solutions are available for large scale stone processing enterprises.
What certifications does this machine have for global sales?
This CNC bridge saw holds CE certification (mandatory for legal sales and customs clearance in European markets) andISO quality management system certification. The ISO certificate is globally recognized, verifying our standardized production and stable quality control system, delivering reliable machine performance and trustworthy service for worldwide customers.
