55kw Main Power Stone Cutting Machine for Precise Cutting Performance
1.Smart Inverter Control System
Adjustable left-right feeding speed tailored to stone hardness (granite, marble, etc.)
Energy-saving operation with real-time RPM optimization
2. Hydraulic Lifting & Precision Drive
1320mm lifting stroke with hydraulic stability
High-precision screw nut driving for forward/backward slicing (±0.5mm tolerance)
3. Automated Cutting Excellence
One-touch automatic slicing mode
Imported alloy steel components for durability
4. Groundbreaking Design
Ground-level block placement eliminates crane dependency
15m³/h water cooling system for dust-free operation
Parameter | Unit | BTC-2200 | BTC-2500 | BTC-2800 |
Max blade diameter | mm | Φ2200 | Φ2500 | Φ2800 |
Left and right travel | mm | 3800 | 3500 | 3200 |
Moving front & back travel | mm | 2200 | 2200 | 2200 |
Lifting stroke | mm | 1320 | 1320 | 1320 |
Main motor | kW | 45/55 | 45/55 | 55/65 (Optional) |
Gross power | kW | 57/67 | 57/67 | 67/77 (Optional) |
Outline dimension | mm | 8000×4800×3700 | 8000×4800×3700 | 8000×4800×3700 |
Water consumption | m³/h | 15 | 15 | 15 |
Gross weight | kg | ≈14,000 | ≈14,500 | ≈15,000 |
Support and Services
- Installation guidance and setup assistance for the machine.
- Troubleshooting support for any technical issues that may arise.
- Training sessions for operators on how to use the machine efficiently.
- Regular maintenance services to ensure optimal performance and longevity of the equipment.
Packing and Shipping
Product Packaging
The Machine is carefully packed in a sturdy wooden crate to ensure safe transportation. The machine is securely fixed within the crate to prevent any damage during shipping.
Shipping
We ship the Machine worldwide using trusted shipping services. The machine is shipped in a protective wooden crate to safeguard it from any potential damage during transit. Customers will receive tracking information once the order is shipped to monitor the delivery status.
