1.5-Axis CNC Precision Control
◦ 5-axis linkage CNC system enables simultaneous movement across multiple axes, allowing for complex 3D cuts, curves, and angles with micron-level accuracy.
◦ Supports arbitrary-shaped lines, fan-shaped plates, wash basins, and special-shaped edge profiling for limitless design possibilities.
2. Advanced Drive & Stability
◦ Bus-based absolute value servo system with power-off memory ensures uninterrupted operations and precise repositioning after shutdown.
◦ High-precision linear guide rails and ball screw transmission guarantee smooth motion and minimal vibration for flawless finishes.
3. Oil-Immersed Track Structure
◦ Enhanced durability and reduced wear with a rust-resistant, oil-lubricated track design, ensuring long-term stability in demanding environments.
4. Multi-Functional & Space-Efficient
◦ Compact footprint maximizes workshop space while delivering multiple processing functions (cutting, shaping, edging).
◦ User-friendly interface simplifies operation, reducing training time and human error.
5. Wide-Ranging Applications
◦ Perfect for natural stone, marble, granite, quartz, and engineered stone.
◦ Ideal for countertops, sinks, decorative panels, architectural elements, and custom-shaped components.
|
Parameter
|
Unit
|
Create 450
|
Create 600
|
|
Blade diameter range
|
mm
|
350-450
|
350-600
|
|
Max processing size
|
mm
|
3200*2000*120
|
3400*2000*180
|
|
Lifting stroke
|
mm
|
300
|
500
|
|
Worktable size
|
mm
|
3200*2000
|
3400*2000
|
|
Table tilting degree
|
°
|
0-85°
|
0-85°
|
|
Head rotating degree
|
°
|
0-360°
|
0-360°
|
|
Air speed
|
m/min
|
15
|
15
|
|
Repeated accuracy of positioning
|
mm
|
0.1mm/1000
|
0.1mm/1000
|
|
Main motor
|
kw
|
18.5(Permanent magnetic system synchronous motor)
|
22(Permanent magnetic system synchronous motor)
|
|
Gross power
|
kw
|
26
|
30
|
|
Water consumption
|
m³/h
|
3
|
3
|
|
Outline dimension
|
mm
|
5600*3600*3500
|
5800*3650*3900
|
|
Head tilting degree
|
°
|
0-90°
|
0-90°
|
|
Gross weight
|
kg
|
6000
|
7500
|
Support and Services
- Installation guidance and setup assistance for the machine.
- Troubleshooting support for any technical issues that may arise.
- Training sessions for operators on how to use the machine efficiently.
- Regular maintenance services to ensure optimal performance and longevity of the equipment.
Packing and Shipping
Product Packaging
The Machine is carefully packed in a sturdy wooden crate to ensure safe transportation. The machine is securely fixed within the crate to prevent any damage during shipping.
Shipping
We ship the Machine worldwide using trusted shipping services. The machine is shipped in a protective wooden crate to safeguard it from any potential damage during transit. Customers will receive tracking information once the order is shipped to monitor the delivery status.
