Product Description:
The Bridge Cutting Machine is perfect for cutting marble and other stones. It is a versatile machine that can be used for a variety of cutting applications. Its blade diameter of 350-450mm makes it an ideal choice for cutting through even the toughest of materials. The water consumption of 3m3/H ensures that the blade stays cool and lubricated throughout the cutting process, which ensures that the quality of the cuts is always high.
Technical Parameter
| Parameter |
Unit |
Expand 450 |
Expand 450FA |
| Control system type |
/ |
4 Axis System |
Normal 5 Axis System |
| Blade diameter |
mm |
350-450 |
350-450 |
| Worktable size |
mm |
3200*2000 |
3200*2000 |
| Max processing size |
mm |
3200*2000*100 |
3200*2000*100 |
| Worktable tilting degree |
° |
0-85° |
0-85° |
| Cutting head rotation degree |
° |
0-360° |
0-360° |
| Cutting head rotation control mode |
/ |
Servo motor control |
Servo motor control |
| Cutting head chamfer rotating degree |
° |
0-45° |
0-45° |
| Main motor power |
kw |
15 |
15 |
| Outline dimension |
mm |
5000*3100*2700 |
5000*3100*2700 |
| Water consumption |
m³/h |
3 |
3
|
Applications:
- Granite cutting for kitchen and bathroom countertops
- Marble cutting for floors, walls, and decorative features
- Bridge cutting for larger slabs and projects
Support and Services:
- Installation and setup assistance
- Training for operators and maintenance personnel
- Troubleshooting and repair services
- Spare parts and accessories replacement
- Regular maintenance and calibration services
- Software upgrades and updates
- Remote technical support through phone or email
- On-site technical support upon request
Packing and Shipping:
Product Packaging:
The Bridge Saw Cutting Machine will be carefully packaged in a sturdy wooden crate to ensure safe transportation. The machine will be wrapped in protective material and secured to prevent any damage during shipping.
Shipping:
The Bridge Saw Cutting Machine will be shipped via a reputable carrier, such as FedEx or UPS. The shipping cost will be calculated based on the destination and weight of the package. The estimated delivery time will be provided to the customer upon purchase.
