This state-of-the-art four column middle block cutting machine delivers unrivaled precision, high-speed operation, and durability. Engineered for granite, marble, and thick slab processing, it's an essential asset for businesses seeking to enhance productivity and cutting quality.
Attribute | Value |
---|---|
Power Supply | AC |
Safety System | Available |
Gross Power | 29/37kw |
Trolley Size | 3000*2000mm |
Water Consumption | 4m3/H |
Main Motor | 15/18.5KW |
Blade Diameter | 700-1400mm |
Warranty | 1 Year |
Parameter | Unit | MGKQ-1200 | MGKQ-1400 |
---|---|---|---|
Blade diameter range | mm | 700-1200 | 1000-1400 |
Trolly size | mm | 3000*2000 | 3000*2000 |
Worktable rotating angle | ° | 0-90° | 0-90° |
Main motor | kw | 22-6/30-6(optional) | 22-8 |
Gross power | kw | 29/37(optional) | 30 |
Outline dimension | mm | 6150*4800*4000 | 6150*4800*4300 |
Gross weight | kg | 7300 | 7600 |
Water consumption | m³/h | 4 | 4 |
The four-column design ensures exceptional stability during operation, minimizing vibrations for precise cuts in granite, marble, and thick slabs. The precisely aligned columns guarantee cutting tolerances within fractions of a millimeter, meeting the highest industry standards.
Built with robust steel alloys for superior wear resistance, this machine withstands continuous industrial use. The cutting components are engineered for easy replacement, ensuring long service life and reduced maintenance costs.
