Hydraulic Multiblade Bridge Cutting Machine For Granite Blocks

1set
MOQ
To Be Negotiated
Price
Hydraulic Multiblade Bridge Cutting Machine For Granite Blocks
Features Gallery Product Description Request A Quote
Features
Specifications
Model NO.: BTC-2800
Control: PLC
Max Blade Diameter: Φ2800mm
Max Processing Length: 3200mm
Max Processing Width: 2200/2500mm
Max Lifting Stroke: 1300mm
Water Consumption: 15m3/H
Main Motor: 45/55kw
Gross Motor: 56/66kw
Outline Dimension: 7800*4500/4800*3700mm
Gross Weight: 14500kg
Blade: Multi-Blades
Transport Package: Load In A 40 Feet Container
Specification: 7800*4500/4800*3700mm
Trademark: UNIQUE
Origin: Jinjiang, Fujian, China
HS Code: 84641090
Supply Ability: 1000 Sets/Year
Type: Bridge Cutting Machine
Usage: Granite
Application: Construction
Source Voltage: 380V
Automation: Automatic
Cutting Ability: High Speed
Customization: Available | Customized Request
Highlight:

Multiblade Bridge Cutting Machine

,

Granite Blocks Cutting Machine

,

Hydraulic Bridge Cutting Machine
Basic Infomation
Place of Origin: China
Brand Name: Unique
Certification: API
Model Number: BTC-2800
Payment & Shipping Terms
Packaging Details: Plastic Package, Suitable for Sea Transportation.
Payment Terms: L/C, T/T
Supply Ability: 1000 Sets Per Year
Product Description
Hydraulic Multiblade Bridge Cutting Machine For Granite Blocks
Product Specifications
Attribute Value
Model NO. BTC-2800
Control PLC
Max Blade Diameter Φ2800mm
Max Processing Length 3200mm
Max Processing Width 2200/2500mm
Max Lifting Stroke 1300mm
Water Consumption 15m3/H
Main Motor 45/55kw
Gross Motor 56/66kw
Outline Dimension 7800*4500/4800*3700mm
Gross Weight 14500kg
Blade Multi-Blades
Transport Package Load in a 40 Feet Container
Specification 7800*4500/4800*3700mm
Trademark UNIQUE
Origin Jinjiang, Fujian, China
HS Code 84641090
Supply Ability 1000 Sets/Year
Type Bridge Cutting Machine
Usage Granite
Application Construction
Source Voltage 380V
Automation Automatic
Cutting Ability High Speed
Customization Available
Product Overview

The BTC-2800 Hydraulic Multiblade Bridge Cutting Machine is designed for efficient granite block processing. Featuring inverter-controlled left-right feeding with adjustable speed and a hydraulic lifting system with four guide poles, this machine delivers exceptional performance.

Hydraulic Multiblade Bridge Cutting Machine For Granite Blocks 0
Key Features
  • Guide sleeve with multi-function layer seals for waterproof, dustproof, and anti-spill protection
  • High-precision screw nut driving for forward-backward slicing
  • Automatic slicing capability
  • Main spare parts made from imported high-quality materials
  • Blocks can be placed directly on the ground
  • High cutting efficiency and slicing precision
  • Excellent plate flatness after cutting
  • Stable operation and easy to use
  • Optional 360° rotating worktable available
Technical Parameters
Parameter Unit BTC-2200 BTC-2500 BTC-2800
Max blade diameter mm 2200 2500 2800
Max processing length mm 3600 3300 3200
Max processing width mm 2200 2200 2800
Max lifting stroke mm 1350 1350 1350
Water consumption m3/h 15 15 15
Main motor kw 45/55 45/55 55
Gross motor kw 56/66 56/66 66
Outline dimension mm 8000*4800*3700 8000*4800*3700 8000*4800*3700
Gross weight kg 14000 14500 15000
Our Services
  • Comprehensive training on machine installation and operation
  • Overseas engineer support for machinery servicing
  • 24-hour online after-sales service
  • Dedicated support from sales and customer service departments
Frequently Asked Questions
Does this product support customization?

Yes, the BTC-2800 Hydraulic Multiblade Bridge Cutting Machine is available with customization options to meet specific requirements.

How do you ship the products?

The machine is shipped in a 40-foot container for secure transportation.

What is the warranty for the product?

Please contact our sales department for detailed warranty information specific to your purchase.
