Home /Products/Diamond Wire Saw Machine/CNC Profilling Diamond Wire Saw Machine With High Cutting Precision for Tombstone

CNC Profilling Diamond Wire Saw Machine With High Cutting Precision for Tombstone

1
MOQ
To Be Negotiable
Price
CNC Profilling Diamond Wire Saw Machine With High Cutting Precision for Tombstone
Features Gallery Product Description Request A Quote
Features
Specifications
Advantage: Multi Function With Good Quality And Price
Cutting Precision: High
Wire Speed: 0-40m/S
Model NO.: DTWS-1500/2000
Max Processing Size: 3500*3500*2100mm
Diameter: 8.5mm To 11.5mm
Gross Motor: 11kw
Main Motor: 15kw
Adjustment Distance: 450mm
Warranty Time: One Year
Wire Length: 10m
Trolley Size: 1500*2500mm
Transport Package: Plastic Package, Suitable For Sea Transportation
Water Consumption: 4m3/H
Table Bearing Weight: 15T
Automation: Automatic
Wire Diameter: 7.2-11mm
Control Type: CNC
Name: Diamond Wire Saw Machine
Control: CNC
Spindle: 15KW
Basic Infomation
Place of Origin: Jinjiang, Fujian, China
Brand Name: Xianda Machinery
Certification: API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
Model Number: DTWS-1500
Payment & Shipping Terms
Packaging Details: Plastic Package, Suitable for Sea Transportation
Delivery Time: 15-30days
Payment Terms: L/C， T/T， D/P， Western Union ，Paypal ，Money Gram， Others
Supply Ability: 1000 Sets/Year
Product Description
CNC Profiling Diamond Wire Saw Machine With High Cutting Precision for Tombstone

CNC Control Diamond Wire Saw Machine with High Cutting Precision and Four-Spindle Linkage for Stone Cutting. Diamond Wire Saw Machine is an advanced and reliable cutting solution for special shape stone. Designed with four-spindle linkage and diamond wire saw for accurate cutting with high precision and quality. Equipped with CNC control system for easy operation.

CNC Profiling Diamond Wire Saw Machine
Technical Specifications
Model Number DTWS-1500 DTWS-2000 DTWS-2000SA
Control System CNC CNC CNC
Certifications API, CCC, SONCAP, GOST, ISO, CE, SGS API, CCC, SONCAP, GOST, ISO, CE, SGS API, CCC, SONCAP, GOST, ISO, CE, SGS
Trolly size 1500*2500mm 1500*2500mm 1500*2000mm
Gross Weight 7000kg 7500kg 8000kg
Outline Dimension 6300*6300*3300mm 6800*6300*3300mm 6800*6300*3600mm
Max Processing Size 1500*3000*1200mm 2000*3000*1200mm 2000*3000*1200mm
Water Consumption 3m³/H 3m³/H 3m³/H
Main Motor 11KW 11KW 11KW
Table Bearing Weight 15T 15T 15T
Wire Speed 20-40m/s 20-40m/s 20-40m/s
Production Capacity 1000 Sets/Year 1000 Sets/Year 1000 Sets/Year
Origin Jinjiang, Fujian, China Jinjiang, Fujian, China Jinjiang, Fujian, China
Applications

DTWS-1500 CNC wire cutting machine (rope saw) function: Cutting column slabs, semi circular slabs, English letters, and other diversified complicated special shapes. Materials include marble, granite, natural stone, etc.

  • Heavy load bearing structure with four orbits on each upright column, adjusted balance by rollers, with less friction and higher precision
  • Left and right frame achieve synchronized lifting by steering equipment on upper frame with increased accuracy via lead screw and double nuts
  • Cantilever part with lead screw and pole adjusting guide wheel distance, CNC-controlled guide wheel rotation angle
  • Worktable running by lead screw and railway
  • Automatic wire break alarm system
  • 1600mm aluminum wheel diameter with oil pump controlled rope tension
Key Features
Heavy load bearing structure with four orbits on each upright column
Synchronized lifting with increased accuracy via lead screw and double nuts
Cantilever part with CNC-controlled guide wheel distance and rotation angle
Worktable running by lead screw and railway
Automatic wire break alarm system
1600mm aluminum wheel diameter with oil pump controlled rope tension
Four-spindle linkage for precise cutting operations
Factory Strength
Factory manufacturing facility
  • 40+ years manufacturing experience in stone cutting machinery
  • Export to 60+ countries worldwide
  • Professional R&D team for CNC cutting equipment
  • Full OEM/ODM customization support
  • Complete production line & strict quality inspection
  • After-sales service & technical support globally
Our Team
Professional team members Technical team at work
Packaging & Shipping

Securely packed in specialized packaging material with bubble wrap or foam protection. Shipping options include ground, air, and international shipping. All shipments are tracked and insured for safe delivery.

Packaging process Shipping preparation Packaging diagram
Frequently Asked Questions
What materials can the four-spindle diamond wire saw machine cut?
It can cut granite, marble, quartz, artificial stone, and other hard stones.
What is the cutting precision of this CNC diamond wire saw?
High cutting precision up to ≤0.01mm, ensuring smooth and accurate cutting.
Do you support customized size and parameters?
Yes, we provide full OEM/ODM customization for table size, power, voltage and functions.
Can you export to Europe, USA, Middle East and Southeast Asia?
Yes, we have rich export experience and provide safe packaging and fast delivery.
What is the advantage of four-spindle linkage?
It improves cutting efficiency, stability and multi-angle processing capacity.
