Features

Specifications

Cutting Materials: Marble, Granite, Quartzite, Sandstone, And Other Natural/synthetic Stones.

Main Motor Power: 11kw

Wire Speed: 20-40m/s

Wire Diameter: Φ8 Mm – Φ11.5 Mm (diamond-coated Wire For Precision Cutting)

Wire Length: Standard Lengths: 14.7m 15.7m 16.7m

Worktable Size: Models: 3000×2000 Mm, 4000×2500 Mm, 5000×3000 Mm (custom Sizes Available).

Worktable Load Capacity: Up To 15Theavy-duty Structural Design).

Worktable Rotation: 360° Continuous Rotation For Multi-angle Profiling.

Cutting Mode: Dry Cutting Or Wet Cutting

Cutting Precision: Tolerance: ±0.1 Mm (high-precision Linear Guides And Ball Screws).

Application Scenarios: Tone Fabrication, Architectural Decoration, Tombstone Carving, Sculpture Manufacturing, And Industrial Stone Processing.

Wheel Diameter: 1600mm

Gross Weight: 5500kg

Water Consumption: 3m³/h

Basic Infomation

Place of Origin: Jinjiang, Fujian, China

Brand Name: XIANDA MACHINERY

Certification: API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF

Model Number: CNC-2000/2500/3000

Payment & Shipping Terms

Packaging Details: Plastic Package, Suitable For Sea Transportation

Delivery Time: 1 Month

Payment Terms: L/C， T/T， D/P， Western Union ，Paypal ，Money Gram， Others

Supply Ability: 1000 Sets/Year

Gallery

CNC Diamond Wire Saw Stone Cutting Machine for profiling

Product Description

CNC Diamond Wire Saw Stone Cutting Machine for profiling

Revolutionize Your Stone Profiling with Our CNC Diamond Wire Saw Stone Cutting Machine

Technical parameter

Parameter	Unit	CNC-2000	CNC-2500	CNC-3000
Max processing size	mm	200030001500	250030001500	300030001500
Wheel diameter	mm	1600	1600	1600
Trolley size	mm	1300*2500	1300*2500	1300*2500
Table bearing weight	T	15	15	15
Main motor	kw	11	11	11
Wire speed	m/s	20~40	20~40	20~40
Outline dimension	mm	680063003800	780063003800	880063003800
Gross weight	kg	5500	5750	6000
water consumption	m³/h	3	3	3

Unmatched Precision

Powered by an advanced CNC system, our machine ensures cutting precision within ±0.1mm. Whether you're working on intricate tombstone carvings or large - scale architectural decorations, the high - precision linear guides and ball screws guarantee flawless results every time.

High - Speed and Versatile

With a variable wire speed of 20-40 m/s and the ability to cut a wide range of materials including marble, granite, and quartzite, this machine boosts your productivity. The 360° rotating worktable enables multi - angle profiling, while the maximum cutting size of up to 3,000×3,000×1,500mm (L×W×H) accommodates various project scales and accept customized processing size.

Robust and Reliable

Featuring a main motor power of up to 11KW and a worktable load capacity of 15T, our cutting machine can handle heavy - duty tasks with ease. You can choose between dry and wet cutting modes, and the optional dust collection or water recycling system ensures a clean and sustainable operation.

Customizable Solutions

Available in multiple models with customizable worktable sizes and wire lengths, our CNC diamond wire saw machine caters to your specific needs.

Upgrade your stone profiling process today. Contact us for a quote and witness the future of stone cutting technology!
