65kw Precision Block Cutting Machine For Granite, Marble
Product Specifications
| Operation |
Automatic, Manual |
| Cutting Speed |
High Speed |
| Cutting Method |
Laser Cutting |
| Weight |
6500KG |
| Voltage |
220V/380V |
| Material |
Casting |
| Cutting Depth |
95/100/120mm |
| Max Processing Diameter |
2800mm |
Precision Block Cutting Machine For Granite, Marble
Transform your stone processing operations with our Block Cutting Machine, engineered to deliver precision, efficiency, and reliability for granite and marble cutting tasks.
Key Features & Technical Advantages
Intelligent Inverter-Powered Feeding System
Our machine features state-of-the-art inverter technology that controls the left-right feeding mechanism, enabling precise speed adjustment based on stone hardness and characteristics. This adaptive system optimizes cutting performance while reducing material waste and extending blade lifespan.
Advanced Hydraulic & Screw Nut Driven Slicing
- Hydraulic Lifting System: Robust mechanism ensures seamless vertical movement for precise blade positioning
- High-Precision Screw Nut Driving: Guarantees consistent, accurate cuts with every pass
- Automatic Slicing Function: Eliminates human error and ensures uniform thickness across all slices
Technical Parameters
| Parameter |
Unit |
BTC-2200 |
BTC-2500 |
BTC-2800 |
| Max blade diameter |
mm |
2200 |
2500 |
2800 |
| Left and right travel |
mm |
3800 |
3500 |
3200 |
| Moving front&back travel |
mm |
2200 |
2500 |
2800 |
| Lifting stroke |
mm |
1320 |
1320 |
1320 |
| Main motor |
kw |
45/55 |
45/55 |
55/65 |
| Gross power |
min/m² |
57/67 |
57/67 |
67/77 |
| Water consumption |
m³/h |
15 |
15 |
15 |
| Gross weight |
kg |
14000 |
14500 |
15000 |
Premium Imported Components
We use rigorously tested imported materials for all main components, ensuring superior performance, stability, and longevity even under continuous heavy-duty operation.
Space-Saving & Cost-Effective Design
Our ground-level block placement design eliminates the need for elevated platforms, saving workspace while reducing installation and maintenance costs.
Unmatched Performance Benefits
- High Cutting Efficiency: Maximize output with rapid slab production
- Superior Slicing Precision: Achieve smooth, flat surfaces requiring minimal finishing
- Exceptional Stability: Reliable performance for continuous operation
- User-Friendly Operation: Intuitive controls suitable for all skill levels
Ideal Applications
Perfect for both large-scale stone manufacturers and small workshops, our Block Cutting Machine offers an advanced solution for processing high-value granite and marble blocks.
Why Choose Our Block Cutting Machine?
- Proven Technology: Incorporates latest stone cutting advancements
- Tailored Support: Comprehensive technical assistance and training
- Customer-Centric Service: Seamless experience from purchase to after-sales
Contact us today to learn how our High-Performance Block Cutting Machine can transform your stone processing business and elevate your productivity.
