| Attribute | Value |
|---|---|
| Trademark | Xianda |
| Power Source | Electric |
| Cutting Speed | 0-40m/s |
| Transport Package | Load In A 20 Feet Container |
| Gross Motor | 11kw |
| Origin | Fujian, China |
| Water Consumption | 4m3/H |
| Control Type | CNC |
1. CNC Control & Four-Spindle Linkage
Automated precision meets multi-axis coordination for flawless complex cuts and consistent repeatability.
2. Multi-Functional Processing
Effortlessly create:
3. High-Quality Construction
Industrial-grade components ensure durability for demanding production environments.
4. Micron-Level Precision
Achieve smooth finishes and ±0.1mm tolerances with diamond-coated wire technology.
5. User-Friendly Interface
Simplify operations with intuitive programming and real-time monitoring.
| Parameter | Unit | CNC-2000 | CNC-2500 | CNC-3000 |
|---|---|---|---|---|
| Max processing size | mm | 2000*3000*1500 | 2500*3000*1500 | 3000*3000*1500 |
| Wheel diameter | mm | 1600 | 1600 | 1600 |
| Worktable size | mm | 1300x2500 | 1300x2500 | 1300x2500 |
| Table bearing weight | 15 | 15 | 15 | |
| Main motor | kw | 11 | 11 | 11 |
| Wire speed | m/s | 0~40 | 0~40 | 0~40 |
| Outline dimension | mm | 6800*6300*3800 | 7800*6300*3800 | 8800*6300*3800 |
| Gross weight | kg | 5500 | 5750 | 6000 |
Product Packaging:
The Machine is carefully packed in a sturdy wooden crate to ensure safe transportation. The machine is securely fixed within the crate to prevent any damage during shipping.
Shipping:
We ship the Machine worldwide using trusted shipping services. The machine is shipped in a protective wooden crate to safeguard it from any potential damage during transit. Customers will receive tracking information once the order is shipped to monitor the delivery status.
