BLMM-1800MAX-A Heavy-Duty CNC Linear Profiling & Milling Machine with High-Precision CNC Control and Dual-Function Milling & Profiling

1
MOQ
BLMM-1800MAX-A Heavy-Duty CNC Linear Profiling & Milling Machine with High-Precision CNC Control and Dual-Function Milling & Profiling
Features Gallery Product Description Request A Quote
Features
Specifications
Blade Diameter: 400-700mm
Lifting Travel: 600mm
Processing Length: 3500mm
Main Motor: 18.5kw
Gross Power: 24kw
Outline Dimension: 4350*6300*3600
Highlight:

High-Precision CNC Control CNC Linear Profiling & Milling Machine

,

Heavy-Duty Structural Design Stone Processing Machine

,

Dual-Function Milling & Profiling Heavy-Duty CNC Machine

Basic Infomation
Place of Origin: Quanzhou,China
Brand Name: XIADNA
Certification: CE/SEO
Model Number: BLMM-1800MAX-A
Payment & Shipping Terms
Packaging Details: Plastic package
Delivery Time: 15-30 working days after received deposit
Payment Terms: T/T
Supply Ability: 500sets per month
Product Description
BLMM-1800MAX-A Heavy-Duty CNC Linear Profiling & Milling Machine
Product Overview

Designed for high-precision stone processing, the BLMM-1800MAX-A combines advanced linear profiling and CNC milling capabilities. Built to handle heavy stone materials including granite, marble, quartz, and sintered stone, this machine delivers exceptional precision for complex contours, decorative moldings, balustrades, and architectural stone components.


Key Features & Capabilities
  • Dual-Function Milling & Profiling: Seamlessly integrates continuous contour profiling with high-efficiency milling to reduce production handling times.

  • Heavy-Duty Structural Design: Built with high-rigidity cast iron and reinforced guide rails to ensure zero vibration during high-speed cutting.

  • High-Precision CNC Control: Features an intuitive CNC interface supporting multi-axis movement for automated, repeatable, and complex geometric designs.

  • Superior Surface Finish: Advanced spindle dynamics and precise motion control deliver smooth edge profiles, significantly minimizing manual polishing work.

  • Dust & Water Protection: Fully sealed slide ways and automatic lubrication systems prolong machine lifespan in harsh stone workshop environments.

Machine Parameter
Parameter BLMM-1800MAX-A
Blade diameter 400-700mm
Lifting travel 600mm
Processing length 3500mm
Main motor 18.5kw
Gross power 24kw
Y axis transmission structure Walking wheel
Y axis transmission mode Single Y axis drive
Outline dimension 4350*6300*3600
Water consumption ≈3
Warranty Coverage

All machines and core components come with a 12-month warranty, ensuring peace of mind for your purchase.

Comprehensive Support

We offer full guidance on installation and machine operation.

International service support is available from our experienced technical team.

24/7 online after-sales assistance—get help whenever you need it.

Have questions? Our sales and customer service teams are always ready to assist you promptly.
