Name: Planar Stone Carving Machine China Portable CNC Router / Wood CNC Carving Machine
Brand: Fujian Xianda Machinery co.,ltd
SKU: SEM-1625/1825/2030-2D
Price: 17,511.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Highlight:

Portable Stone Carving CNC Router

Precision Stone Carving CNC Router

Basic Infomation

Place of Origin: Jinjiang, Fujian, China

Brand Name: Xianda Machinery

Certification: CCC, SONCAP, GOST, ISO, CE,The Right of Final Explanation Belongs to Xianda

Model Number: SEM-1625/1825/2030-2D

Payment & Shipping Terms

Delivery Time: 30 days

Payment Terms: L/C,D/P,T/T,D/A,Western Union

Supply Ability: 1000 Sets/Year

Gallery

Planar Stone Carving Machine China Portable CNC Router / Wood CNC Carving Machine

Product Description

Planar Stone Carving Machine - Portable CNC Router/Wood CNC Carving Machine

Product Overview

This CNC stone carving machine features numerical control system, three-axis linkage, double row four-row slider, constant power spindle motor, and two-way tool cooling system. It offers stable operation, high precision, and efficiency for processing marble, granite, bluestone, jade, agate, copper plate, and aluminum plate.

Technical Specifications

Parameter	Unit	SEM-1325	SEM-1625	SEM-1825
Dimension	mm	1300×2500	1600×2500	1800×2500
Feed height	mm	≤350	≤350	≤350
Air speed	m/min	15	15	15
Number of spindles	pcs	1	1	1
Spindles power	kw	5.5	5.5	5.5
Outline dimension	mm	2360×3600×2200	2660×3600×2200	2860×3600×2200
Water consumption	m³/h	1	1	1

Parameter	Unit	SEM-1625-2D	SEM-1825-2D	SEM-2030-2D
Dimension	mm	1600×2500	1800×2500	2000×3000
Feed height	mm	≤350	≤350	≤350
Air speed	m/min	15	15	15
Number of spindles	pcs	2	2	2
Spindles power	kw	5.5	5.5	5.5
Outline dimension	mm	2660×3600×2200	2860×3600×2200	3060×4100×2200
Water consumption	m³/h	2	2	2

Key Features

CNC control system for precise operation
Three-axis linkage for complex carving
Double row four-row slider for stability
Constant power spindle motor (5.5kw)
Two-way tool cooling system
High-speed cutting capability (15m/min)
Multiple spindle options (1 or 2 pcs)
Certified with ISO, CE, CCC, GOST, SONCAP

Manufacturer Information

Fujian Xianda Machinery Co., Ltd. has been manufacturing stone processing machinery since 1985. As a top 5 stone cutting machine manufacturer with ISO & CE certification, we hold 70% of China's market share in special shape stone cutting machines.

Quality Assurance

Each machine undergoes strict inspection before shipping
Testing video available upon request
One year warranty on all machines
24/7 technical support
Professional installation guidance available

Frequently Asked Questions

Q: How to place an order?

A: 1. Inquiry → 2. Confirm details → 3. Receive proforma invoice → 4. Make deposit payment → 5. Production begins

Q: What about after-sales service?

A: We provide 24-hour online support, engineer dispatch for assembly, and one year parts warranty.

Q: What materials can this machine process?

A: Designed for marble, granite, bluestone, jade, agate, copper and aluminum plates.
