Granite Quarrying Diamond Wire Saw Rope 11.5mm Line Speed 22-25m/S

50m
MOQ
US $38/Meter
Price
Granite Quarrying Diamond Wire Saw Rope 11.5mm Line Speed 22-25m/S
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Diamond Wire Saw
Application: Cutting,Granite Quarrying
Material: Diamond,steel,Diamond Wire Saw,rubber
Usage: Granite Quarrying,Rock Cutting,Stone Carving,diamond Wire Saw
Product Name: 11.5mm Fast Cutting Rope Quarry Diamond Wire Saw,Small Diameter Diamond Wire Saw For Stone Cutting,Diamond Saw Ropes
Advantage: High Efficiency Long Life Time,High Working Efficiency,high Quality,Fast Cutting,15 Years Experience
Beads Type: Sintered
Diameter: 11.5mm
Business Type: Manufacturer,Manufacturer And Trading
Highlight:

22m s Diamond Wire Saw Rope

,

22m s diamond wire saw stone cutting

,

25m s Diamond Wire Saw Rope
Basic Infomation
Place of Origin: China
Brand Name: Unique
Model Number: GQR115
Payment & Shipping Terms
Packaging Details: 50cm*50cm*30cm
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000m/day
Product Description
Granite Quarrying Diamond Wire Saw Rope 11.5mm Line Speed 22-25m/S
Product Attributes
Attribute Value
Type diamond wire saw
Application Cutting, Granite Quarrying
Material Diamond, steel, Diamond wire saw, rubber
Usage Granite Quarrying, Rock cutting, Stone Carving, diamond wire saw
Product name 11.5mm fast cutting rope quarry diamond wire saw, Small diameter Diamond wire saw for stone cutting, Diamond saw ropes
Advantage High Efficiency Long Life Time, High working efficiency, high quality, Fast Cutting, 15 years experience
Beads type Sintered
Diameter 11.5mm
Business type Manufacturer, Manufacturer and Trading
Diamond Wire Saw For Granite Quarrying Tools
Basic Information
  • Model NO.: Diamond Wire Saw For Granite Quarrying
  • Service: ODM, OEM, Customized
  • Beads Number: 40 Beads Per Meter
  • Business Type: Manufacturer
  • Keywords: Marble /Quarring/Stone/Concrete Cutting Diamond Wire
  • Grade: a-Grade
  • Usage: Used on Electric Wire Saw Machine
  • Shipping: by Air, by Sea, by Express(DHL,FedEx,EMS)
  • Beads Type: Sintered, Electroplated, Brazed
  • Transport Package: Sealed and Waterproof Plastic Box Packaging
  • Specification: D11.5mm
  • Trademark: UNIQUE
  • Origin: China
  • Production Capacity: 1000meters/Day
Product Features
  • The diamond wire quarrying technique can highly improve the quarrying efficiency, reduce the waste of mining resource
  • It can exploit large dimension blocks while being operated safely and is good for environment protection
  • Independently developed special rubber and vulcanized technique ensures performance in all sorts of bad environments
  • The rubber and cable stick together tightly for good bonding and more strikes during work
  • The vulcanised rubber easily withstands temperature increases caused by badly controlled water spraying
  • Strong flexibility reduces the cut-in-one-side problem and protects cable well when used for small curvature radius
Technical Specifications
Specification Reinforcement Beads number Cutting material Line speed Cutting speed Wire life
Φ11.5mm Rubber 40/m Hard granite 18-22m/s 7-10 m²/h 8-15m²/m
Φ11.5mm Rubber 40/m Middle hard granite 22-25m/s 10-15 m²/h 15-25m²/m
Φ11.5mm Rubber 40/m Soft granite 25-30m/s 15-20 m²/h 25-40m²/m
