Precision Column Profiling Machine with Cutting Force Large Capacity Low Noise Level

1 SET
MOQ
To be negotiable
Price
Precision Column Profiling Machine with Cutting Force Large Capacity Low Noise Level
Features Gallery Product Description Request A Quote
Features
Specifications
Cutting Force: High
Outline Dimension: 3500*1300*2800mm
Cutting Accuracy: High
Noise Level: Low
Name: Column Profiling Machine
Cutting Capacity: Large
Gross Power: 12.5kw
Max Processing Diameter(3 PCS): 450-1400mm
Highlight:

Large Capacity Column Profiling Machine

,

Low Noise Level Column Profiling Machine

,

Precision Column Profiling Machine

Basic Infomation
Place of Origin: Jinjiang, Fujian, China
Brand Name: XIANDA MACHINERY
Certification: API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
Model Number: SHM-200/400-2
Payment & Shipping Terms
Packaging Details: Plastic Package, Suitable for Sea Transportation
Delivery Time: 1 month
Payment Terms: L/C, T/T, D/P, Western Union ,Paypal ,Money Gram, Others
Supply Ability: 1000 Sets/Year
Product Description
Precision Column Profiling Machine with Cutting Force Large Capacity Low Noise Level
Key Attributes
Attribute Value
Cutting Force High
Outline Dimension 3500*1300*2800mm
Cutting Accuracy High
Noise Level Low
Name Column Profiling Machine
Cutting Capacity Large
Gross Power 12.5kw
Max Processing Diameter (3 PCS) 450-1400mm
Technical Specifications
Parameter SHM-200/400-2 CHM-200/400-2
Maximum blade diameter 500mm
Max processing diameter 200/2pcs 400/1pcs
Processing length 50-1500mm
Main motor 11/15kw (optional)
Gross power 15.5kw 19.5kw (optional)
Outline dimension 3500*1300*2800mm
Gross weight 3000kg
Water consumption 3m³/h

This machine adopts PLC/CNC control, three inverter, simple and practical structure, high efficiency. Dedicated to the processing of baluster, kingpost, roadblock and others.

Features
  • Product Name: Column Cutting Machine
  • Also Known As: Column Profiling Machine
  • Main Motor: 11/15kw
  • Material: Casting
  • Power Supply: AC
Applications

Whether it's for commercial construction projects, monumental stone crafting, or precision stone shaping, the XIANDA MACHINERY Column Cutting Machine is your go-to equipment. This machine is particularly well-suited for occasions where high precision is paramount, such as in the creation of intricate column designs, detailed sculptures, and bespoke architectural elements.

The high cutting accuracy ensures that even the most complex of designs can be executed with sharp, clean cuts. The machine's application scenarios range from high-end custom stonework to mass production of stone columns, demonstrating both versatility and performance.

Customization & Ordering
Detail Specification
Brand Name XIANDA MACHINERY
Place of Origin Jinjiang, Fujian, China
Certification API, CCC, SONCAP, GOST, ISO, CE, SGS, IAF
Minimum Order Quantity 1 SET
Price To be negotiable
Packaging Details Plastic Package, Suitable for Sea Transportation
Delivery Time 1 month
Payment Terms L/C, T/T, D/P, Western Union, Paypal, Money Gram, Others
Supply Ability 1000 Sets/Year
Packing and Shipping

The Column Cutting Machine is securely packaged in a heavy-duty, industrial-grade wooden crate, designed to protect the machinery during transportation. The crate is reinforced with metal brackets and padded internally with shock-absorbing foam to prevent any damage from movement or impact.

Prior to shipping, the crate undergoes a thorough inspection to guarantee that it meets all safety and quality standards. We offer a range of shipping options, including standard ground shipping, expedited services, and international logistics. Each shipment is fully insured and comes with a tracking number.
