High Cutting Accuracy Four Cylinder Gantry Stone Machine For Slab

1 SET
MOQ
To be negotiable
Price
High Cutting Accuracy Four Cylinder Gantry Stone Machine For Slab
Features Gallery Product Description Request A Quote
Features
Specifications
Max Diameter Of Cylinder: 2500mm
Max Vertical Lifting Travel: 1500mm
Power Consumption: Low
Max Worktable Travel: 3000mm
Main Motor: 22/30kw
Name: Column Profiling Machine
Cutting Accuracy: High
Gross Power: 26.5/34.5kw
Outline Dimension: 3800*6300*4850mm
Water Consumption: 8m3/H
Gross Weight: 8000kg
Highlight:

Four Cylinder Gantry Stone Machine

,

Slab Gantry Stone Machine

,

30kw Column Cutting Machine

Basic Infomation
Place of Origin: Jinjiang, Fujian, China
Brand Name: XIANDA MACHINERY
Certification: API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
Model Number: YHQJ-2500
Payment & Shipping Terms
Packaging Details: Plastic Package, Suitable for Sea Transportation
Delivery Time: 1 month
Payment Terms: L/C, T/T, D/P, Western Union ,Paypal ,Money Gram, Others
Supply Ability: 1000 Sets/Year
Product Description
High Cutting Accuracy Four Cylinder Gantry Stone Machine For Slab
Product Specifications
Attribute Value
Max Diameter of Cylinder 2500mm
Max Vertical Lifting Travel 1500mm
Power Consumption Low
Max Worktable Travel 3000mm
Main Motor 22/30kw
Name Column Profiling Machine
Cutting Accuracy High
Gross Power 26.5/34.5kw
Outline Dimension 3800*6300*4850mm
Water Consumption 8m3/H
Gross Weight 8000kg
Technical Parameters
Parameter Unit YHQJ-2500
Max column of diameter mm 2500
Lifting travel mm 1500
Front&back slice travel mm 3000
Main motor kw 22/30
Gross power kw 26.5/34.5
Outline dimension mm 3800*6300*4850
Gross weight kg 8000
Water consumption m³/h 8
High Cutting Accuracy Four Cylinder Gantry Stone Machine For Slab 0 High Cutting Accuracy Four Cylinder Gantry Stone Machine For Slab 1 High Cutting Accuracy Four Cylinder Gantry Stone Machine For Slab 2
Product Overview

The Column Profiling Machine is a powerful and efficient grinder machine with a lifting travel of 1500mm and large cutting capacity. Designed for column cutting and profiling applications, this machine offers:

  • High cutting accuracy for precise results
  • Low noise operation for improved work environment
  • Gross power of 26.5/34.5kw for heavy-duty performance
  • Durable polishing mechanism for smooth, accurate finishes
  • Robust construction for long-term reliability
Applications

The Column Profiling Machine from XIANDA MACHINERY is a high-accuracy, multi-function polishing and stone profiling solution. Certified by API, CCC, SONCAP, GOST, ISO, CE, SGS, and IAF, this machine is ideal for:

  • Heavy-duty stone profiling operations
  • Precision column cutting applications
  • Large-scale industrial stone processing
  • Various shapes and sizes of column processing
Customization Options

XIANDA MACHINERY Column Profiling Machine

  • Brand Name: XIANDA MACHINERY
  • Model Number: YHQJ-2500
  • Origin: Jinjiang, Fujian, China
  • Certifications: API, CCC, SONCAP, GOST, ISO, CE, SGS, IAF
  • Minimum Order: 1 SET
  • Packaging: Plastic, suitable for sea transportation
  • Delivery Time: 1 month
  • Payment Options: L/C, T/T, D/P, Western Union, PayPal, Money Gram
  • Annual Capacity: 1000 Sets
Support and Services
Online Support

Submit requests online for timely technical assistance from our support team.

Telephone Support

Call our technical hotline for immediate advice and troubleshooting.

On-site Support

Our technicians can provide on-site diagnosis, repair, and training services.

Packing and Shipping

The Column Cutting Machine is securely packaged in foam-filled cardboard boxes, sealed for transit protection. We ship worldwide via reliable carriers to ensure safe and timely delivery.

Frequently Asked Questions
Q: What is the Brand Name of this Column Cutting Machine?

A: The Brand Name is XIANDA MACHINERY.

Q: What is the Model Number of this Column Cutting Machine?

A: The Model Number is YHQJ-2500.

Q: Where is this Column Cutting Machine made?

A: Manufactured in Jinjiang, Fujian, China.

Q: What certifications does this machine have?

A: Certified by API, CCC, SONCAP, GOST, ISO, CE, SGS, and IAF.

Q: What is the minimum order quantity?

A: Minimum order is 1 SET.
